Gantry type CNC plasma and flame cutting machine/ oxy-fuel cutter

FOB Reference Price:Get Latest Price
$5,000.00 - $25,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
QG series
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 20 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Shandong, China (Mainland)
Brand Name:
HAUFEI
Voltage:
380V can be customized
Rated Power:
standard
Dimension(L*W*H):
According to the Machine Model
Certification:
CE ISO
Warranty:
1 Year
After-sales Service Provided:
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Engineers available to service machinery overseas
color:
Customized
cutting mode:
Oxy-fuel(flame), plasma
Cutting speed:
0-6000mm/min
Flame cutting thickness:
6-200mm
Plasma cutting thickness:
Depending on the plasma power source
Control system:
Option
Product name:
Gantry type CNC plasma and flame cutting machine/ oxy-fuel cutter
Cutting material:
Metal Stainless Steel Carbon Steel Aluminum
Power:
Japan famous power source
Weight:
According to model
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
sea worthy package with film and wooden case
Port
qingdao port China
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 20 To be negotiated
Video Description

Gantry type CNC plasma and flame cutting machine/ oxy-fuel cutter

Product Description

Track width (mm)

3000

3500

4000

5000

6000

7000

Working width (mm)

2200

2700

3200

4200

5200

6200

Overall width (mm)

3800

4300

4800

5800

6800

7800

CNC system

Micro Edge pro, or famous domestic brands according to customer's requirements

Cutting mode

Flame cutting and plasma cutting

Driven system

Double-side Panasonic servo driven system

Torch lifting stroke (mm)

Optional

Idle stroke speed (mm/min)

0-10000

Cutting speed (mm/min)

0-4000

Flame cutting thickness (mm)

6-200

Fuel gas type

Acetylene,propane,natural gas

Plasma cutting thickness

Decided by plasma power source

Foundation type

H-beam steel or cement base, standard configuration is H-beam steel

Note :

(1)Above is standard configuration of our products.

(2)Track guage can be customized according to your require.

(3)Track length can be customized according to your require.

Product Display



Feature:



1. Welded steel frame structure, annealing treatment after welding, to eliminate internal stress, without deformation in the long-term use

2. All the mechanical transmission system adopts precision rolling bearing and machining 7GB precision gear and rack meshing

3. Drive system using Japan Shimpo planetary reducer, the input, output error only 16 minutes of arc. At the same time, in the horizontal and vertical gear transmission structure, add an automatic clearance compensation device, the transmission structure be able to accurately perform NC system instruction

4. Guide: the rail adopts linear slide type, precise walking on two tracks

5. All equipment and spare parts, with black, electroplating and other surface treatment

6. Sandblasting spray primer, topcoat with orange paint, the color is blue



                                          Control System                                                                          Programming Software

 MicroEdge pro,or famous domestic brands according to       Australia Fast Cam Nesting software(professional version)

 customer's requirments.





                 Horizontal Straight Guiding Rail                                          7-Grade Precision Rack

 Longitudinal and transversal rails use domestic or imported      Transversal,longitudinal transmission from Germany

 linear guide, high precision and good guidance.                        NEUGART high precision, high torque, low backlash,

                                                                                                    maintenance-free planetary gear reducer







                  Japan Panasonic Servo Motor                                                       Dust Cover

Servo drive with Panasonic servo drive system with                    Optional dust or fume treatment working table

position detection function, exercise high precision, speed,        create a good working environment.

speed range, acceleration time is short.







Packaging & Shipping

Company Information

    Self-discipline and Social Commitment, we strive to be the best. By Self-Motivation, national brand can be established. Since established, Jinan Huafei CnC Machine Co.,Ltd. has focused on introducing and cultivating high-tech talents and takes it as development strategy. at present, many professionals have been brought together who specialize in researching and developing of uncoiling and leveling machines, CnC welding and cutting equipments. technical strength is always cherished as core competitiveness of our company.

    With constant efforts of all staffs, our products have been sold well in domestic market and exported to many countries in the world, including Australia, Indonesia, India, Burma, Iran, Spain, Brasil, Peru, Russia, Azerbaijan, KZ, uZ, Sri Lanka, etc. During establishing the national brand of Huafei, we always hold the responsibility of culture communication between china and the world.

    On your way in life and career, HUAFEI can be your loyal friend, we can establish our own national brand and witness prosperous future in a harmonious world.









Our Services

Since establishment, extensive experience has been accumulated and advanced QMS and professional after-sales service been built. Our HUAFEI brand

machineries are produced strictly under the requirement of ISO9001 and professional after-sales service well provided by our experienced and devoted after-sales staffs.

1-Warranty: one year warranty from the date of delivery (excluding quick-wear parts), free repairing service for non-artificial damages within guarantee period, also free service can be provided only with spare parts charged after warranty period expires.

2-Training: Technicians will be sent for installing and commissioning, after testing, free training will be provided till operation mastered and machine running normal.

3-Maintenance: Once faults occur out of no particular reason, technicians will be sent for repairing within 24 hours (48 hours for out-of-province) after receiving notice.

4-Parts: spare parts are available all the time for customers.

5-Documents: relevant documents, operation instruction, parts description etc, will be provided after contract comes into effect.
6-Technical support: technical support and maintenance will be provided by professional technicians during machine usage.



FAQ



A1:Yes, In order to give you a suitable plasma machine,pls tell me the max working area, materials for processing and the thickness for materials processing engraving or cutting. Then perfect suitable plasma machine will be recommended



Q2:When the machine can’t work well,What should I do?

 A2. Engineer is online for 24 hours, they can check the problems and then give you a solutions in two hours.Our machine is with one’s year warranty, If any problems of machine parts under “normal use”,new machine parts will be sent by air In free.Please rest assured that operation CD and manual will be offered along with machine,making you can operate the machine easily.
